CR-HC8220X
Superisys
| Availability: | |
|---|---|
| Quantity: | |
• Compact fixed industrial barcode reader designed for difficult scenes.
• Built-in high-performance AI barcode reading algorithm, maximum reading speed 310 codes/second
• High signal-to-noise ratio imaging design, optimized for industrial difficult code reading.
• Simplified setting process, one-click automatic tuning
• Equipped with various types of light sources, with modulated lighting design, no fear of complex scene.
| Minimum Order Quantity | 1 |
| Delivery Time | 8 Work Days |
| Stock | In Stock |
| Payment Terms | T/T, Western Union |
| Model | CR-HC8220X-08RA | CCR-HC8220X-12RA | CCR-HC8220X-12RA |
| Barcode Type | 1D: Code39，Code93，Code128，CodaBar，EAN8，EAN13 TF25，UPCA，UPCE，INDUSTRIAL25; 2D: QRCode ，Data Matrix\ | ||
| Max. acquisition frame rate | 30fps | ||
| Max.reading speed | 60pcs/second | ||
| Sensor type | 20-second rolling shutter CMOS | ||
| Resolution | 5120*3840 | ||
| Exposure time | 16μm-1sec | ||
| Communication protocol | TCP Client、TCp Server、Etheret/lP、 ModBus TCP Server.Modbus TCP client, RS232, UDP client,UDP server,profinet | ||
| Data interface | Fast Ethernet(100Mbit/s) | ||
| Digital IO | 17-pin M12 interface provides power and I/O: including 3 non-isolated inputs (Line INO/1/2) 3 non-isolated outputs (Line Out0/1/2), 1 RS232 input, 1 RS232 output Supports triggering the device via the top button | ||
| Power supply | 24VDC 1A | ||
| Max. power consumption | 15 W@24 VDC (with built-in fill light enabled) | ||
| Focal length | 8mm | 12mm | 16mm |
| Recommended working distance | 40-400mm | 60-600mm | 100-600mm |
| Interface | M12-Mount, Autofocus | ||
| Light source | Focused white light, transparent lens cover, optional red light, | ||
| Indicator light | 3 Status indicator | ||
| Size | -20°C~+70°C | ||
| Weight | 230g | ||
| Temp. | working : 0-50℃ Storage: -30℃-70℃ | ||
| Humidity | 20%-95%RH（No condensation） | ||
| Certificate | CE, RoHS,KC | ||
• Compact fixed industrial barcode reader designed for difficult scenes.
• Built-in high-performance AI barcode reading algorithm, maximum reading speed 310 codes/second
• High signal-to-noise ratio imaging design, optimized for industrial difficult code reading.
• Simplified setting process, one-click automatic tuning
• Equipped with various types of light sources, with modulated lighting design, no fear of complex scene.
| Minimum Order Quantity | 1 |
| Delivery Time | 8 Work Days |
| Stock | In Stock |
| Payment Terms | T/T, Western Union |
| Model | CR-HC8220X-08RA | CCR-HC8220X-12RA | CCR-HC8220X-12RA |
| Barcode Type | 1D: Code39，Code93，Code128，CodaBar，EAN8，EAN13 TF25，UPCA，UPCE，INDUSTRIAL25; 2D: QRCode ，Data Matrix\ | ||
| Max. acquisition frame rate | 30fps | ||
| Max.reading speed | 60pcs/second | ||
| Sensor type | 20-second rolling shutter CMOS | ||
| Resolution | 5120*3840 | ||
| Exposure time | 16μm-1sec | ||
| Communication protocol | TCP Client、TCp Server、Etheret/lP、 ModBus TCP Server.Modbus TCP client, RS232, UDP client,UDP server,profinet | ||
| Data interface | Fast Ethernet(100Mbit/s) | ||
| Digital IO | 17-pin M12 interface provides power and I/O: including 3 non-isolated inputs (Line INO/1/2) 3 non-isolated outputs (Line Out0/1/2), 1 RS232 input, 1 RS232 output Supports triggering the device via the top button | ||
| Power supply | 24VDC 1A | ||
| Max. power consumption | 15 W@24 VDC (with built-in fill light enabled) | ||
| Focal length | 8mm | 12mm | 16mm |
| Recommended working distance | 40-400mm | 60-600mm | 100-600mm |
| Interface | M12-Mount, Autofocus | ||
| Light source | Focused white light, transparent lens cover, optional red light, | ||
| Indicator light | 3 Status indicator | ||
| Size | -20°C~+70°C | ||
| Weight | 230g | ||
| Temp. | working : 0-50℃ Storage: -30℃-70℃ | ||
| Humidity | 20%-95%RH（No condensation） | ||
| Certificate | CE, RoHS,KC | ||
Automotive parts traceability
Read the QR code of parts on the welding/assembly line, bind production data to the MES system, and achieve full life cycle tracking.
Express logistics sorting
Integrated in the sorting machine, high-speed identification of the parcel surface single barcode, improve sorting accuracy and throughput.
Drug packaging supervision
Scan the QR code of the drug packaging to verify the batch information to ensure compliance and anti-counterfeiting traceability.
Food production traceability
Read the laser marking code on the metal can body and record key data such as production time and production line number.
Warehouse inventory management
Fixed installation on the shelf channel, automatically scan the pallet barcode, and update the inventory status in real time.
Automotive parts traceability
Read the QR code of parts on the welding/assembly line, bind production data to the MES system, and achieve full life cycle tracking.
Express logistics sorting
Integrated in the sorting machine, high-speed identification of the parcel surface single barcode, improve sorting accuracy and throughput.
Drug packaging supervision
Scan the QR code of the drug packaging to verify the batch information to ensure compliance and anti-counterfeiting traceability.
Food production traceability
Read the laser marking code on the metal can body and record key data such as production time and production line number.
Warehouse inventory management
Fixed installation on the shelf channel, automatically scan the pallet barcode, and update the inventory status in real time.
FAQ
Q1: Can the Barcode Reader scan normally in a strong light environment?
A: Yes. The device has built-in anti-reflection algorithms and adaptive LED fill light, which can cope with direct sunlight or high-intensity lighting environments.
Q2: Does it support reading barcodes on curved surfaces?
A: Yes. Through dynamic focal length adjustment, barcodes on cylindrical containers (such as beverage bottles) or curved metal parts can be read.
Q3: How to clean the lens and protective cover?
A: The IP67 design can be wiped directly with a wet cloth to avoid the use of corrosive solvents. Regular monthly maintenance is recommended.
Q4: Can it be connected to the existing WMS/MES system?
A: Yes. Provide standard communication protocols (TCP/IP, PROFINET) and API interfaces for quick connection to enterprise management systems.
Q5: Does the device installation require professional debugging?
A: Plug-and-play design, providing autofocus and parameter preset functions, ordinary engineers can complete deployment within 15 minutes.
FAQ
Q1: Can the Barcode Reader scan normally in a strong light environment?
A: Yes. The device has built-in anti-reflection algorithms and adaptive LED fill light, which can cope with direct sunlight or high-intensity lighting environments.
Q2: Does it support reading barcodes on curved surfaces?
A: Yes. Through dynamic focal length adjustment, barcodes on cylindrical containers (such as beverage bottles) or curved metal parts can be read.
Q3: How to clean the lens and protective cover?
A: The IP67 design can be wiped directly with a wet cloth to avoid the use of corrosive solvents. Regular monthly maintenance is recommended.
Q4: Can it be connected to the existing WMS/MES system?
A: Yes. Provide standard communication protocols (TCP/IP, PROFINET) and API interfaces for quick connection to enterprise management systems.
Q5: Does the device installation require professional debugging?
A: Plug-and-play design, providing autofocus and parameter preset functions, ordinary engineers can complete deployment within 15 minutes.
