Size(mm)41*29*9mm,High temperature bearing body,RFID carrier identified by 8k bit tool,
T/T, Western Union
1000 per day
Technical Parameters
Model
RF-UZMTC8921-H9
Air mouth agreement
ISO 18000-6C Class 1 Gen 2
Working frequency
860~960 MHz
Chip
Alien H9
EPC memory size
496 Bits
USER memory size
688Bits
TID
48 Bits
Size (mm)
89*21*12mm
Canning material
ABS
Way to install
Screwing or Gluing
Class
IP65
Weight
15g
Operating temperature
-25℃~70℃
Storage temperature
-30℃~85℃
Metal resistance
Antimetal
Read distance
0-10m
Payment & Shipping Terms
Minimum Order Quantity
Price
Delivery Time
Stock
Description
Payment Terms
Supply Ability
one
Large quantity price negotiable
5-8 Work Days
In Stock
Size(mm)41*29*9mm,High temperature bearing body,RFID carrier identified by 8k bit tool,
T/T, Western Union
1000 per day
Technical Parameters
Model
RF-UZMTC8921-H9
Air mouth agreement
ISO 18000-6C Class 1 Gen 2
Working frequency
860~960 MHz
Chip
Alien H9
EPC memory size
496 Bits
USER memory size
688Bits
TID
48 Bits
Size (mm)
89*21*12mm
Canning material
ABS
Way to install
Screwing or Gluing
Class
IP65
Weight
15g
Operating temperature
-25℃~70℃
Storage temperature
-30℃~85℃
Metal resistance
Antimetal
Read distance
0-10m
UHF Anti metal Tag Features
This series of tags is primarily used for RFID identification of precision products and jigs. Its operating frequency is 860-960MHz and supports the ISO 18000-6C Gen2 Class1.
This tag incorporates a high-performanceantenna design. Both its production and design processes have undergone strict testing. Advanced manufacturing techniques have been adopted during its production, endowing it with features such as high temperature resistance 230℃, anti-metal interference, accurate read/write distance, high sensitivity, and consistent performance.
Product Applications
The UZMT series UHF Anti metal tag is suitable for industrial applications in high temperature, long-distance, anti-metal, and complex outdoor environments.
Application scenarios can be divided into:
Embedded installation in the threading of metal work-in-progress items.
High-temperature resistant embedded installation on the surface of mold tags.
Installation applications on outdoor vehicle surfaces, characterized by stable identification and strong sensitivity.
UHF Anti metal Tag Features
This series of tags is primarily used for RFID identification of precision products and jigs. Its operating frequency is 860-960MHz and supports the ISO 18000-6C Gen2 Class1.
This tag incorporates a high-performanceantenna design. Both its production and design processes have undergone strict testing. Advanced manufacturing techniques have been adopted during its production, endowing it with features such as high temperature resistance 230℃, anti-metal interference, accurate read/write distance, high sensitivity, and consistent performance.
Product Applications
The UZMT series UHF Anti metal tag is suitable for industrial applications in high temperature, long-distance, anti-metal, and complex outdoor environments.
Application scenarios can be divided into:
Embedded installation in the threading of metal work-in-progress items.
High-temperature resistant embedded installation on the surface of mold tags.
Installation applications on outdoor vehicle surfaces, characterized by stable identification and strong sensitivity.
